FQ2 User’s Manual
Run Tab Page (from Setup Display)
Tool
Setup Mode
Continuous test
Model region Same as for the Search item settings. Scene
Insp. region Scene
Adjust judgement Adjusts judgement parameters without
stopping measurements.
--- Scene p. 175
Auto adjustment Automatically adjusts the judgement
parameters by using actual workpieces
which are considered as good or faulty
products.
OK Teach, NG Teach
Method Selects the expression to use to auto-
matically adjust the judgement parame-
ters.
Threshold (minimum), Threshold (aver-
age) (default), or Threshold (maximum)
Auto display (trend
monitor and histo-
gram only)
Same as the trend monitor and histogram for [Run] Mode. --- p. 184,
p. 185
Display range (trend
monitor and histo-
gram only)
Number of data
(trend monitor only)
p. 184
Number of data
(histogram only)
p. 185
Erase display
Save data Saves scene data, Calibration data, and
system data.
--- --- p. 178
Menu command Description Setting range Data Refer-
ence
Switch to Run mode Switches to Run Mode. --- --- p. 180
Menu command Description Setting range Data Refer-
ence
Select scene --- --- p. 190
Select Switches to a registered scene. ---
Rename Used to delete, copy, or change the
name of a scene.
15 alphanumeric characters
Copy ---
Clear
Menu command Description Setting range Data Refer-
ence
