External Reference Parameters
452
FQ2 User’s Manual
121 Model
region
Rotation Setting/Acqui-
sition
0: No, 1: Yes 0 --- ---
122 Rotation angle upper
limit
Setting/Acqui-
sition
−180 to 180 180 --- ---
123 Rotation angle lower
limit
Setting/Acqui-
sition
−180 to 180 −180 --- ---
132 Detec-
tion coor-
dinate
Detection point X Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
0 --- ---
133 Detection point Y Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
0 --- ---
134 Mea-
sure-
ment
condition
Sub-pixel Setting/Acqui-
sition
0: No, 1: Yes 0 --- ---
136 Judge-
ment
condi-
tions
Judgement upper limit
for search coordinate X
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
137 Judgement lower limit
for search coordinate X
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
138 Judgement upper limit
for search coordinate Y
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
99,999.9999 --- Adjust judge-
ment
139 Judgement lower limit
for search coordinate Y
Setting/Acqui-
sition
−99,999.9999 to
99,999.9999
−99,999.9999 --- Adjust judge-
ment
140 Judgement upper limit
for search angle
Setting/Acqui-
sition
−180 to 180 180 --- Adjust judge-
ment
141 Judgement lower limit
for search angle
Setting/Acqui-
sition
−180 to 180 −180 --- Adjust judge-
ment
142 Judgement upper limit
for correlation
Setting/Acqui-
sition
0 to 100 100 --- Adjust judge-
ment
1
43 J
udgement lower limit
for correlation
Setting/Acqui-
sition
0 to 100 60 --- Adjust judge-
ment
146 Mea-
sure-
ment
condi-
tions
Sort condition Setting/Acqui-
sition
For Multiple Searches
0: Ascending order of corre-
lation value,
1: Descending order of cor-
relation value,
2: Ascending order of posi-
tion X,
3: Descending order of
position X,
4: Ascending order of posi-
tion Y,
5: Descending order of
position Y
1 --- ---
148 Judge-
ment
condi-
tions
Judgement upper limit
for detection count
Setting/Acqui-
sition
0 to 32 32 --- Adjust judge-
ment
149 Judgement lower limit
for detection count
Setting/Acqui-
sition
0 to 32 0 --- Adjust judge-
ment
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
