No. Name Setting Range Default
o2-04 Drive Model Selection -
Depending on drive
size
Note: 1. Refer to Defaults by Drive Capacity (o2-04) and ND/HD (C6-01) on page 183 for a list of o2-04 settings and parameters that change
depending on the drive model selection.
2. Drive performance will suffer if the correct drive capacity is not set to o2-04, and protective functions will fail to operate properly.
n
o2-05: Frequency Reference Setting Method Selection
Determines if the ENTER key must be used to input a frequency reference from the digital operator.
No. Name Setting Range Default
o2-05 Frequency Reference Setting Method Selection 0 or 1 0
Setting 0: ENTER Key Required
Every change in the frequency reference setting on the digital operator has to be finalized by pressing the ENTER key
before it becomes effective.
Setting 1: ENTER Key Not Required
The
output frequency changes immediately when the reference is changed by the UP and DOWN key on the digital operator.
The ENTER key does not need to be pressed. The frequency reference is saved five seconds after the Up or DOWN key
has been released.
n
o2-06: Operation Selection when LED Operator is Disconnected
Determines if the drive will stop when an external LED operator (JVOP-182) is removed in LOCAL mode or with b1-02
set to 0.
No. Name Setting Range Default
o2-06 Digital Operator Disconnection Operation 0 or 1 0
Setting 0: Continue Operation
The operation is continued.
Setting 1: Trigger a Fault
The operation is stopped and an “oPr” fault is triggered. The motor coasts to stop.
n
o2-09: Initialization Specification Selection
This parameter sets the regional specifications for the drive and should not be changed.
u
o3: Copy Function
Use
o3 parameters to Read, Copy, and Verify the parameter settings to and from the drive using an LED operator (option).
n
o3-01 Copy Function Selection
Parameter o3-01 selects the copy function operation.
No. Name Setting Range Default
o3-01 Copy Function Selection 0 to 3 0
0: No Action
No action.
1: READ
All parameters are copied from the drive to the LED operator.
2: WRITE
All parameters are copied from the LED operator to the drive.
3: VERIFY
Parameter settings in the drive are compared to those in the LED operator.
Note: When using the copy function, the drive model number (o2-04) and the software number (U1-14) must match or an error will occur.
n
o3-02 Copy Function READ Permission
Parameter o3-02 can be used to prevent accidentally overwriting the data stored in the operator.
No. Name Setting Range Default
o3-02 Copy Function READ Permission 0, 1 0
5.9 o: Operator Related Settings
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
