D.2 European Standards
Figure D.1 CE Mark
The CE mark indicates compliance with European safety and environmental regulations and is required for engaging in
business and commerce in Europe.
European
standards include the Machinery Directive for machine manufacturers, the Low Voltage Directive for electronics
manufacturers and the EMC guidelines for controlling noise.
This drive displays the CE mark based on the EMC guidelines and the Low Voltage Directive.
• EMC Guidelines: 2004/108/EC
• Low Voltage Directive: 2006/95/EC
u
CE Low Voltage Directive Compliance
This drive has been tested according to IEC61800-5-1:2007, and it fully complies with the Low Voltage Directive.
To
comply with the Low Voltage Directive, be sure to meet the following conditions when combining this drive with other
devices:
n
Area of Use
Do not use drives in areas with pollution higher than severity 2 and overvoltage category 3 in accordance with IEC664.
n
Installing Fuses on the Input Side
Always install input fuses. Select fuses according to Table D.1.
Table D.1 Recommended Input Fuse Selection
Drive Model
JZA
Class T Fuses
Model Fuse Ampere Rating
200 V Class Single-Phase Drives
B0P1 A6T15 15
B0P2 A6T20 20
B0P4 A6T20 20
B0P7 A6T40 40
B1P5 A6T40 40
200 V Class Three-Phase Drives
20P1 A6T10 10
20P2 A6T10 10
20P4 A6T15 15
20P7 A6T20 20
21P5 A6T25 25
22P2 A6T30 30
24P0 A6T40 40
400 V Class Three-Phase Drives
40P2 A6T10 10
40P4 A6T10 10
40P7 A6T20 20
41P5 A6T25 25
42P2 A6T25 25
43P0 A6T25 25
44P0 A6T30 30
n
Grounding
The
drive is designed to be used in T-N (grounded neutral point) networks. If installing the drive in other types of grounded
systems, contact your dealer for instructions.
u
EMC Guidelines Compliance
This drive is tested according to IEC61800-3:2004 and it complies with the EMC guidelines.
D.2 European Standards
212
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
