1.3 Component Names
This section illustrates the drive components as they are mentioned in this manual.
u
IP20/Open-Chassis
n
Single-Phase AC200 V JZAB0P1B ~ JZAB0P4B
Three-Phase AC200 V JZA20P1B ~ JZA20P7B
K
A
B
C
D
E
G
H
J
I
F
A –
Fan cover
<1>
B
– Mounting hole
C – Heatsink
D – Cable cover
E – Terminal cover
F – Front cover screw
G – Option connector cover
H – Front cover
I – LED operator Refer to Using the Digital LED
Operator on page 54
J – Case
K –
Cooling fan
<1>
Figure 1.2 Exploded View of IP20/Open-Chassis Type Components Three-Phase AC200 V JZA20P7B
<1>
The drives JZAB0P1B ~ JZAB0P4B and JZA20P1B ~ JZA20P4B do not have a cooling fan or a cooling fan cover.
1.3 Component Names
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
19
1
Receiving
