Omron J1000 User Manual

u
H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
H1: Multi-Function Digital Input
H1 parameters to assign functions to the multi-function digital input terminals. Unused terminals should be set to "F".
H1-01
Multi-Function Digital Input
Terminal S1 Function
Selection
Assigns a function to the multi-function digital inputs.
Refer to H1 Multi-Function Digital Input Selections on
page 175 for a description of setting values.
1 to 67
40 O 438 90
H1-02
Multi-Function Digital Input
Terminal S2 Function
Selection
41 O 439 90
H1-03
Multi-Function Digital Input
Terminal S3 Function
Selection
0 to 67
24 O 400 90
H1-04
Multi-Function Digital Input
Terminal S4 Function
Selection
14 O 401 90
H1-05
Multi-Function Digital Input
Terminal S5 Function
Selection
3 (0)
<18>
O 402 90
<18> Parenthetical value is the default when parameter A1-03 = 3330 3-Wire Initialization.
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
0 3-Wire Sequence Closed: Reverse rotation (only if the drive is set up for 3-Wire sequence) 90
1 LOCAL/REMOTE Selection
Open: REMOTE, Run and frequency reference source set in b1-01/02
Closed: LOCAL, LED operator is run and reference source
91
2
Serial Communication Reference
Selection
Open: REMOTE, Run and frequency reference source set in b1-01/02
Closed: MEMOBUS/Modbus Communication
91
3 Multi-Step Speed Reference 1
Used to select Multi-Step Speeds set in d1-01 to d1-08
91
4 Multi-Step Speed Reference 2 91
5 Multi-Step Speed Reference 3 91
6 Jog Reference Selection
Open: Selected speed reference
Closed: Jog Frequency reference (d1-17). Jog has priority over all other
reference sources.
91
7 Accel/Decel Time 1 Used to switch between Accel/Decel Time 1 and 2 91
8 Baseblock Command (N.O.)
Open: Normal operation
Closed: No drive output
91
9 Baseblock Command (N.C.)
Open: No drive output
Closed: Normal operation
91
A Accel/Decel Ramp Hold
Closed: The drive pauses during acceleration or deceleration and maintains the
output frequency.
92
F Not used
Select this setting when not using the terminal or when using the terminal in a
pass-through mode.
92
10 Up Command Open: Maintains the current frequency reference
Closed: Increases or decreases the current frequency reference.
Ensure
that the increase and decrease commands are set in conjunction with one
another.
92
11 Down Command 92
14 Fault Reset Closed: Resets faults if the cause is cleared and the Run command is removed. 93
15 Fast-Stop (N.O.)
Closed: Decelerates at the Fast-Stop time C1-09.
To restart the Fast-Stop input must be released and Run must be cycled.
93
17 Fast-stop (N.C.) Open: Decelerates according to C1-09 (Fast-stop Time) 93
20 to 2F External Fault
20: N.O., Always Detected, Ramp To Stop
21: N.C., Always Detected, Ramp To Stop
22: N.O., During Run, Ramp To Stop
23: N.C., During Run, Ramp To Stop
24: N.O., Always Detected, Coast To Stop
25: N.C., Always Detected, Coast To Stop
26: N.O., During Run, Coast To Stop
27: N.C., During Run, Coast To Stop
28: N.O., Always Detected, Fast-stop
29: N.C., Always Detected, Fast-stop
2A: N.O., During Run, Fast-stop
2B: N.C., During Run, Fast-stop
2C: N.O., Always Detected, Alarm Only (continue running)
2D: N.C., Always Detected, Alarm Only (continue running)
2E: N.O., During Run, Alarm Only (continue running)
2F: N.C., During Run, Alarm Only (continue running)
94
40
Forward Run Command (2-Wire
sequence)
Open: Stop
Closed: Forward run
94
B.2 Parameter Table
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
175
B
Parameter List
