A.2 Single/Three-Phase 200 V Class Drive
Table A.2 Power Ratings
Item Specification
Three-Phase: JZA 20P1 20P2 20P4 20P7 21P5 22P2 24P0
Single-Phase: JZA
<1>
B0P1 B0P2 B0P4 B0P7 B1P5 - -
Maximum Motor Size Allowed (kW)
<2>
HD Rating 0.1 0.2 0.4 0.75 1.5 2.2 4.0
ND Rating 0.2 0.4 0.75 1.1 2.2 3.0 5.5
Input
Input Current (A)
<3>
Three-Phase
HD Rating 0.7 1.5 2.9 5.8 7.5 11.0 18.9
ND Rating 1.1 1.9 3.9 7.3 10.8 13.9 24.0
Single-Phase
HD Rating 1.4 2.8 5.5 11.0 14.1 - -
ND Rating 2.0 3.6 7.3 13.8 20.2 - -
Output
Rated Output Capacity (kVA)
<4>
HD Rating 0.3 0.6 1.1 1.9 3.0 4.2 6.7
ND Rating 0.5 0.7 1.3 2.3 3.7 4.6 7.5
Output Current (A)
HD Rating
0.8
<6>
1.6
<6>
3.0
<6>
5.0
<6>
8.0
<7>
11.0
<7>
17.5
<7>
ND Rating
<5>
1.2 1.9 3.5(3.3) 6.0 9.6 12.0 19.6
Overload Tolerance
ND Rating: 120% of rated output current for 1 minute
HD Rating: 150% of rated output current for 1 minute
(Derating may be required for applications that start and stop frequently)
Carrier Frequency 2 kHz (user-set, 2 to 15 kHz)
Max Output Voltage (V) Three-phase 200 to 240 V (proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: Three-phase 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective Actions DC Reactor Optional
<1> Drives with a single-phase power supply input output three-phase power, and cannot run a single-phase motor.
<2>
The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<3> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to Swing PWM. Current derating is required in order to raise the carrier frequency.
<6> Carrier frequency is set to 10 kHz. Current derating is required in order to raise the carrier frequency.
<7> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
Note: Differences between Heavy Duty (HD) ratings and Normal Duty (ND) ratings for the drive include rated input and output current, overload
capacity, carrier frequency and current limit. Set parameter C6-01 to “0” (default) for HD or “1” for ND.
A.2 Single/Three-Phase 200 V Class Drive
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
163
A
Specifications
