D.4 User Setting Table
No. Name
User
Setting
A1-01 Access Level Selection
A1-03 Initialize Parameters
A1-04 Password 1
A1-05 Password 2
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
b1-03 Stopping Method Selection
b1-04 Reverse Operation Selection
b1-07 Local/Remote Run Selection
b1-08
Run Command Selection while in
Programming Mode
b1-14 Phase Order Selection
b1-17 Run Command at Power Up
b2-02 DC Injection Braking Current
b2-03
DC Injection Braking Time/DC Excitation
Time at Start
b2-04 DC Injection Braking Time at Stop
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
C1-03 Acceleration Time 2
C1-04 Deceleration Time 2
C1-09 Fast-Stop Time
C2-01 S-Curve Characteristic at Accel Start
C2-02 S-Curve Characteristic at Accel End
C2-03 S-Curve Characteristic at Decel Start
C2-04 S-Curve Characteristic at Decel End
C3-01 Slip Compensation Gain
C3-02 Slip Compensation Primary Delay Time
C4-01 Torque Compensation Gain
C6-01 Duty Mode Selection
C6-02 Carrier Frequency Selection
C6-03 Carrier Frequency Upper Limit
C6-04 Carrier Frequency Lower Limit
C6-05 Carrier Frequency Proportional Gain
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
d1-05 Frequency Reference 5
d1-06 Frequency Reference 6
d1-07 Frequency Reference 7
d1-08 Frequency Reference 8
d1-17 Jog Frequency Reference
d2-01 Frequency Reference Upper Limit
d2-02 Frequency Reference Lower Limit
d3-01 Jump Frequency 1
d3-02 Jump Frequency 2
d3-04 Jump Frequency Width
d4-01 Frequency Reference Hold Function Selection
E1-01 Input Voltage Setting
E1-03 V/f Pattern Selection
E1-04 Max Output Frequency
E1-05 Max Voltage
E1-06 Base Frequency
E1-07 Mid Output Frequency
E1-08 Mid Output Frequency Voltage
E1-09 Minimum Output Frequency
E1-10 Minimum Output Frequency Voltage
E2-01 Motor Rated Current
E2-02 Motor Rated Slip
E2-03 Motor No-Load Current
No. Name
User
Setting
E2-05 Motor Line-to-Line Resistance
H1-01
Multi-Function Digital Input Terminal S1
Function Selection
H1-02
Multi-Function Digital Input Terminal S2
Function Selection
H1-03
Multi-Function Digital Input Terminal S3
Function Selection
H1-04
Multi-Function Digital Input Terminal S4
Function Selection
H1-05
Multi-Function Digital Input Terminal S5
Function Selection
H2-01
Terminal MA, MB and MC Function
Selection (relay)
H3-01 Terminal A1 Signal Level Selection
H3-03 Terminal A1 Gain Setting
H3-04 Terminal A1 Bias Setting
H3-13 Analog Input Filter Time Constant
H4-01
Multi-Function Analog Output (Terminal AM
Monitor Selection)
H4-02
Multi-Function Analog Output (Terminal AM
Output Gain)
H4-03
Multi-Function Analog Output (Terminal AM
Output Bias)
H5-01 Drive Node Address
H5-02 Communication Speed Selection
H5-03 Communication Parity Selection
H5-04 Stopping Method After Communication Error
H5-05 Communication Fault Detection Selection
H5-06 Drive Transmit Wait Time
H5-07 RTS Control Selection
H5-12 Run Command Method Selection
H5-13
MEMOBUS Frequency Reference and
Frequency Monitor Unit
L1-01 Motor Overload Protection Selection
L1-02 Motor Overload Protection Time
L1-13
Continuous Electrothermal Operation
Selection
L2-01 Momentary Power Loss Operation Selection
L3-01 Stall Prevention Selection during Accel.
L3-02 Stall Prevention Level during Accel.
L3-04
Stall Prevention Selection during
Deceleration
L3-05 Stall Prevention Selection during Run
L3-06 Stall Prevention Level during Run
L4-01 Speed Agreement Detection Level
L4-07 Frequency Detection Conditions
L5-01 Number of Auto Restart Attempts
L6-01 Torque Detection Selection 1
L6-02 Torque Detection Level 1
L6-03 Torque Detection Time 1
L8-01
Internal Dynamic Braking Resistor Protection
Selection (ERF type)
L8-05 Input Phase Loss Protection Selection
L8-10 Heatsink Cooling Fan Operation Selection
L8-12 Ambient Temperature Setting
L8-18 Soft CLA Selection
L8-35 Side-by-Side Selection
L8-38 Carrier Frequency Reduction
n1-02 Hunting Prevention Gain Setting
n3-13 Overexcitation Deceleration Gain
o1-02 User Monitor Selection After Power Up
o1-03 Digital Operator Display Selection
o2-02 STOP Key Function Selection
D.4 User Setting Table
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
