8.2 Drive Options and Peripheral Devices
The following table of peripheral devices lists the names of the various devices/options available for OYMC drives.
• Peripheral Device Selection: Refer to OYMC catalog for selection and part numbers.
• Peripheral Device Installation: Refer to option manual for option installation instructions.
Table 8.1 Available Peripheral Devices
Option Model Number Description
Power Options
DC Reactor — DC reactor to improve power factor
AC Reactor — AC reactor to improve power factor
Braking Resistor ERF-150WJ Series 3% ED, 150 W braking resistor
Interface Options
Remote LED Operator JVOP-182
Remote operator with LED display and copy function;
Cable length max. 3 m
USB/Copy Unit JVOP-181
Allows the user to copy and verify parameter settings
between drives. Can also be used as adapter to connect
the drive to a PC USB port
Note: SI-232/JC option is required
RS-232C Serial Communication
Interface
SI-232/JC
RS232C communications interface to connect the drive
to a PC or the optional copy unit
Remote Operator Interface SI-232/J
RS232C communications interface for usage with the
external LED operator JVOP-182
Potentiometer Option AI-V3/J
Potentiometer option for setting the frequency reference
directly at the drive
Mechanical Options
Heatsink External Mounting
Attachment
EZZ020568□
Installation kit for mounting the drive with the heatsink
outside of the panel (side-by-side mounting possible)
DIN Rail Attachment EZZ08122□ Installation kit for mounting the drive on a DIN rail
NEMA Type 1 Kit EZZ020564□
Parts to make the drive conform to NEMA Type 1
enclosure
Others
CX-Drive — PC tool for drive setup and parameter management
Communication Options
RS-422/485 Serial
Communications Interface
SI-485/J
Interface for RS-422/485 communications using the
MEMOBUS/Modbus RTU protocol
8.2 Drive Options and Peripheral Devices
150
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
