10.19
ELECTRICAL
10
9924125 - 2013 RANGER RZR / RZR S / RZR 4 Service Manual
© Copyright 2012 Polaris Sales Inc.
Headlamp Housing Removal
1. Disconnect the wire harness from the headlamp bulb.
Be sure to pull on the connector, not on the wiring.
2. Remove the O-rings (A) from the headlamp brackets
on both sides of the headlamp.
3. Remove the adjustment screw (B) from the bracket.
4. Carefully remove the headlamp from the front
bumper.
Headlamp Housing Installation
1. Install the headlamp housing back into the front
bumper.
2. Secure the headlamp housing with the rubber O-rings
(A) on both sides of the headlamp and install the
adjustment screw (B).
3. Reconnect wire harness or re-insert bulb if previously
removed.
4. Adjust headlights using the “Headlight Adjustment”
procedure in this section.
HEAD LIGHTS (LED)
Headlight Adjustment
The headlight beams are adjustable.
1. Place the vehicle on a level surface with the headlight
approximately 25 ft. (7.6 m) from a wall.
2. Measure the distance from the floor to the center of
the headlight and make a mark on the wall at the same
height.
3. With the machine in Park, start the engine and turn the
headlight switch to the LOW position.
4. The most intense part of the LOW beam headlight
beam should be aimed 2 in. (5 cm) below the mark
placed on the wall in Step 2.
NOTE: Rider weight must be included in the seat
while performing this procedure.
5. Adjust the beam to the desired position by loosening
or tightening the (3) T-25 adjustment screws and
moving the lamp to the appropriate height.
