The following table defines which procedures to use to complete setting up partitions and configuring a
control path for each of the possible physical connection points.
Table 7 Control Path Matrix
GUI Menu Path Procedure References
MCB Direct
Connection
FC I/O Blade
Connection
LTO-5
Connection
Setup >
Partitions >
Configure
C
reating Partitions on page
182
Step 1 Step 1 Step 1
Setup >
Connectivity >
Configure FC IO Blade
• Configuring FC I/O Blade
Ports on page 194
• Configuring FC Host Port
Failover on page 198
• Enabling a Disabled
Target Port on page 200
• Configuring Datapath
Conditioning on page 201
• Configuring Switch Zoning
on page 204
Step 2
Setup > Device
> Access
Configuring Host Access
• FC Host LUN Mapping
on
page 204
• Channel Zoning
on page
208
• SCSI Host LUN Mapping
on page 209
• LUN Mapping Wizard
on
page 211
Step 3
Setup > Device
> Access
Step 1 on page 195
Setup > Connectivity > Port
Configuration
Step 2
Setup >
Partitions >
Control Path
Configuring Control Path on
page 215
Step 2
Setup > Device
> Access >
SNW Drives
Selecting a Storage
Networking Drive on page
217 (s)
Step 3
