LBX Board and Terminator
This appendix describes the LBX board and terminator.
LBX Board
A module may contain one of three versions of the LBX board shown in Figure 36.
For information on the LBX terminator, see LBX Terminator
on page 349.
• Library configurations of four modules or fewer may contain LBX2 Gen 1 or Gen 2 boards.
• Library configurations of five to eight modules must contain LBX2 Gen 2 boards.
• Library configurations of nine to twelve modules:
• Modules one through seven must contain LBX2 Gen 2
• Modules eight through twelve must contain LBX2 Gen 3
• If you are adding one or more expansion modules to an existing eight-module library, and the LBX
board is an earlier version, you must remove the LBX board from expansion module seven (position
eight) and replace it with the new version, LBX2 Gen 3.
For instructions on removing and replacing the LBX board and terminator, see the Scalar i2000/i6000
Maintenance Manual.
Note
Red stickers identify the LBX2 Gen 3 board required in the expansion
modules added to a library configuration greater than eight modules.

Quantum Scalar i6000 Specifications

General

Form Factor	Rack-mountable
Interface	Fibre Channel, SAS
Product Type	Tape Library
Cooling	Redundant cooling fans
Dimensions	Varies by configuration
Weight	Varies by configuration
Operating Humidity	20% to 80% non-condensing
Scalability	Scalable
Drive Types	LTO
Redundancy	Redundant power supplies
Management	Web-based management
Tape Technology	LTO
Supported Media	LTO Ultrium 9, LTO Ultrium 8, LTO Ultrium 7, LTO Ultrium 6
Power Supply	Redundant power supplies
Non-operating Humidity	5% to 95% non-condensing
