RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 994
Dec 10, 2015
15.9.1 Address field transmission
Address field transmission is a transmission operation that first executes in I
2
C communication to identify the target for
transfer (slave). After a start condition is generated, an address (7 bits) and a transfer direction (1 bit) are transmitted in one
frame.
Simplified I
2
C
IIC00 IIC01 IIC10 IIC11
Target channel Channel 0 of SAU0 Channel 1 of SAU0 Channel 0 of SAU1 Channel 1 of SAU1
Pins used SCL00, SDA00
Note
SCL01, SDA01
Note
SCL10, SDA10
Note
SCL11, SDA11
Note
Interrupt INTIIC00 INTIIC01 INTIIC10 INTIIC11
Transfer end interrupt only (Setting the buffer empty interrupt is prohibited.)
Error detection flag Parity error detection flag (PEFmn)
Transfer data
length
8 bits (transmitted with specifying the higher 7 bits as address and the least significant bit as R/W control)
Transfer rate Max. fMCK/4 [Hz] (SDRmn[15:9] = 1 or more) fMCK: Operation clock frequency of target channel
However, the following condition must be satisfied in each mode of I
2
C.
• Max. 400 kHz (first mode)
• Max. 100 kHz (standard mode)
Data level Forward output (default: high level)
Parity bit No parity bit
Stop bit Appending 1 bit (for ACK reception timing)
Data direction MSB first
Note To perform communication via simplified I
2
C, set the N-ch open-drain output (EVDD0 tolerance) mode (POMxx = 1)
for the port output mode registers (POMxx) (see 4.3 Registers Controlling Port Function for details). When IIC00,
IIC01, IIC10, IIC11 communicating with an external device with a different potential, set the N-ch open-drain output
(EV
DD0 tolerance) mode (POMxx = 1) also for the clock input/output pins (SCL00, SCL01, SCL10, SCL11) (see 4.4.4
Connecting to external device with different potential (3 V) for details).
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0, 1), mn = 00, 01, 10, 11
To Next Page
