Renesas RL78/F13 User Manual

RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1102
Dec 10, 2015
CHAPTER 17 LIN/UART MODULE (RLIN3)
17.1 Overview
The LIN/UART module is a hardware LIN communication controller that supports LIN Specification Package Revision 1.3,
2.0, 2.1, 2.2 and SAE J2602, and automatically performs frame communication and error determination.
The LIN/UART module is provided with UART mode and can also be used as a UART.
Table 17-1 gives the LIN/UART module specifications and Figures 17-1 and 17-2 show block diagrams of the LIN/UART
module.
Table 17-1. LIN/UART Module Specifications
Item Specifications
Channel count RL78/F13: 1 channel
RL78/F14: 1 to 2 channels
LIN
communication
function
Protocol
LIN Specification Package Revision 1.3, 2.0, 2.1, 2.2 and SAE J2602
Variable frame
structure
Master
 Break (low) transmission width: 13 to 28 Tbits
 Break delimiter transmission width: 1 to 4 Tbits
 Inter-byte space (header): 0 to 7 Tbits (space between Sync field and ID field)
Note 1
 Response space: 0 to 7 Tbits
Note 1
 Inter-byte space: 0 to 3 Tbits (space between data bytes in response area)
 Wake-up: 1 to 16 Tbits
Slave
 Break reception width: 9.5 or 10.5 Tbits [for fixed baud rate]
: 10 or 11 Tbits [for auto baud rate]
 Response space: 0 to 7 Tbits
 Inter-byte space: 0 to 3 Tbits (space between data bytes in response area)
 Wake-up: 1 to 16 Tbits
Checksum
 Automatic operation for both transmission and reception
 Classic or enhanced selectable (for each frame)
Response field
data byte
count
Variable from 0 to 8 bytes
Multi-byte (9 or more bytes) response transmission and reception also possible
Frame
communication
modes
Master
 Mode in which header transmission and response transmission/reception is started
with a single transmission start request
 Mode in which header transmission and response transmission are started with
separate transmission start requests (frame separate mode)
Slave
 Mode in which header is automatically received with fixed baud rate
 Mode in which header is automatically received with the baud rate set according to the
sync field measurement result of the sync field and break field detected
Wake-up
transmission
and reception
LIN wake-up mode provided
 Wake-up transmission (1 to 16 Tbits)
 Wake-up reception
Low width of input signals measured
Status
Master
 Successful frame/wake-up transmission
 Successful header transmission
 Successful frame/wake-up reception
Note 2
 Successful data 1 reception
 Error detection
 Operation mode
(LIN reset mode, LIN wake-up mode, LIN operation mode, LIN self-test mode)
