Paper Feeding: Manual feed (roll feeder optional)
Image Fusing: Heat and pressure type, teflon (upper) and silicone
rubber (lower) rollers
Fusing Lamp: Nichrome wire lamp
(115 V: 1,100 W, 230 V: 1,100 W)
Self-diagnostic Codes: 11 codes, displayed in copy counter
Power Source: 115 V/60 Hz....15 A
220 V/50 Hz....7 A
230 V/50Hz.....7 A
240 V/50 Hz....7 A
Power Consumption: Maximum: 1.4 kW
Warm-up: 1.2 kW
Ready: 0.04 to 1.2 kW
Copy cycle: 1.3 kW
Dimensions (W x D x H): 1,080 x 570 x 490 mm
42.1" x 22.2" x 19.1"
Weight: 76 kg, 167.4 lb
Optional Equipment and Machine Configuration
Configuration
Additional equipment
Main frame Optional equipment
A163 copier
Roll feeder (A571) Table (A714)
Roll cutting rail (A570) --
Side guides (A569) --
Other Optional Equipment
• Paper Spool
• Drum anti-condensation heater
Specifications are subject to change without notice.
SM 1-2 A163
