SERVICE TOOLS
A251/A252 4-10 SM
Output Check Mode Table
Press the Bypass Select key to turn on the selected electrical component. The
status of the component is displayed in the paper length indicator.
To turn off the component, press the Bypass Select key again.
Program No. Electrical Component Note
0Main Motor
1 Toner Supply Clutch
2 Pick off solenoid
3 Registration Clutch
4 Total Counter
5 Pre-transfer Lamp
6 Quenching Lamp
7 Fusing Lamp
8 Exposure Lamp (100% duty ratio)
9 Exposure Lamp (selected ID level)
10 Main Charge Corona
11 Grid Voltage
12 Transfer Charge Corona
13 Not Used
14 Separation Charge Corona
15 to 19 Not Used
20 Bias Voltage for the Image Area
21 Bias Voltage for the Non-image Area
22 Main Charge Corona + Grid Voltage
23
Main Motor + PTL + Bias Voltage for the
Non-image Area + Quenching Lamp
24
Original Feed Motor (Forward)
(A252 copier only)
25
Original Feed Motor (Reverse)
(A252 copier only)
26 Roll Feeder Dehumidity Heaters
27
Roll Feeder Cutter Motor
*Note
28 Roll Feeder Paper Feed Motor
30
Original Feed Motor
(Forward and Reverse)
(A252 copier only)
Original feed motor
operation changes every
time the roll feed key is
pressed.
1st time: Forward
2nd time: Stop
3rd time: Reverse
4th time: Stop
34 Main Switch OFF (Energy Star) Turn off the main switch.
NOTE:
The cutter unit continuously moves between the left and right cutter
switches. The number of the movements (0 ~ 9999) is displayed in the
paper length indicator.
