Ricoh FW780 Service Manual

INSTALLATION PROCEDURE
SM 3-11 B047/B048
Installation
20. Install the toner cartridge [A] as shown.
1) Shake the cartridge 5 to 10 times and insert it into the toner hopper.
2) Peel off the green tape [B] from right to left to expose the clear tape and
toner supply holes.
3) Rotate the knob [C] of the cartridge clockwise until it stops.
B047I507.WMF
[A]
[B]
[C]
