Missing Image Area
Even if you place originals in the ADF or on the exposure glass correctly, margin of a few millimeters on
all four sides of the original might not be copied.
1. 2.0 ± 1.5 mm (0.08 ± 0.06 inch)
2. 4.0 ± 1.0 mm (0.16 ± 0.04 inch)
3. 2.0 ± 1.5 mm (0.08 ± 0.06 inch)
4. 5.0 ± 0.5 mm (0.20 ± 0.02 inch)
• The total missing vertical image area (1+3) is less than 4.0 mm (0.16 inch).
Originals
33
