Roland EGX-350 User Manual

Chapter 6 Maintenance
98
6-2 Maintenance and Inspection
Spindle Maintenance
The spindle unit and the belt are parts that wear out. The replacement cycle varies according to usage conditions, but as a
general guide, you should replace them after every 2,000 hours of use.
This machine is provided with a feature for displaying the total working time of the spindle unit. Refer to this to determine
when replacement is needed.
For information on how to perform replacement, refer to the documentation included with the ZS-35 replacement spin-
dle.
 P. 85, “Submenus”

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
