Roland EGX-350 User Manual

Chapter 3
Basic Operation
3-1 Types of Emergency Stops to Ensure Safety ................................................38
How to Perform an Emergency Stop ................................................................... 38
To Cancel an Emergency Stop ............................................................................ 38
Emergency Stop Due to Opening or Closing the Front Cover............................. 39
3-2 Starting and Quitting ......................................................................................40
How to Start the Machine .................................................................................... 40
Shutdown ............................................................................................................. 41
3-3 Using the Handy Panel ..................................................................................42
3-4 Moving the Cutter ..........................................................................................43
Terms Indicating the Cutter Position .................................................................... 43
Viewing the Cutter Position ................................................................................. 43
Manual Movement ............................................................................................... 44
Moving to a Specic Position Automatically ........................................................ 45
3-5 Spindle Operation ..........................................................................................47
Starting and Stopping Spindle Rotation............................................................... 47
Adjusting the Spindle Speed ............................................................................... 48
3-6 Pausing and Stopping Cutting .......................................................................49
Pausing and Resuming Cutting ........................................................................... 49
Stopping Cutting .................................................................................................. 50
37

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
