Roland EGX-350 User Manual

Chapter 2 Installation and Setup
30
2-3 Cable Connections
Connecting the Handy Panel
Make sure the power to the machine is switched o before attempting to connect or disconnect cables.
Connecting the handy panel while the power is on makes the handy panel unusable.
Insert fully and
securely.
Left side
Handy panel
Cable clamp

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
