Roland EGX-350 User Manual

Manual Movement
When the screen on the handy panel displays any one of the messages shown in the gure below, you can move the cutter
manually using the movement buttons.
 P. 84, “Menu List”
 Each single press of , , , , or performs movement by 0.01 millimeter.
 Holding down , , , , or performs slow continuous movement.
 Holding down while pressing and holding , , , , or performs rapid
continuous movement.
Important!
This operation is not possible in the following cases.
 When engraving is in progress
 When operation is paused
Movement along all axes
(X, Y, and Z)
Movement along only the X
and Y axes
Movement along only the Z axis
(“XXX” is “DOWN,” “SURFACE,”
or “UP.”)
Handy panel
Movement buttons
44
Chapter 3 Basic Operation
3-4 Moving the Cutter

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
