Roland EGX-350 User Manual

3-2 Starting and Quitting
How to Start the Machine
Follow the procedure below to start the machine. When startup is complete, the machine is ready for use.
Procedure

Close the front cover.

Switch on the power switch.
A message like the one shown in the gure ap-
pears on the handy panel’s display screen.
ON
Note: “XXX” indicates the version number of the machine’s rmware.
Chapter 3 Basic Operation
40

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
