Roland EGX-350 User Manual

Chapter 4 Engraving
76
4-9 Performing Engraving
Performing Engraving
Make sure the following tasks have all been completed, then sent the engraving data from the computer and perform
engraving.
 Mounting a Workpiece
 P. 54, “Mounting a Workpiece”
 Cutter Installation
 P. 56 through 74, “Cutter Installation Method 1” through “Cutter Installation Method 4”
 Setting the XY Origin Point
 P. 75, “Setting the XY Origin Point (Home Position)”
For information about creating engraving data, refer to the documentation for the program you’re using to create the
data.

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
