Roland EGX-350 User Manual

91
Chapter 5 Feature reference
This displays the working time of the spindle motor. Use it as a guide for determin-
ing the service life of the spindle unit.
 P. 98,"Spindle Maintenance"
Adjustment Menu (Submenu)
 P. 85, "Submenus"
You can apply correction for X- and Y-axis movement distances.
 Default setting: 100%
 Setting range: 99.5 to 100.5%
Executing this menu item performs surface-leveling cutting to adjust the atness
and parallelism of the table surface.
 P. 83, "Surface Leveling of the Workpiece Table"
5-5 Description of Menu Items

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
