Roland EGX-350 User Manual

Chapter 2 Installation and Setup
33
2-4 Selecting the Language
Selecting the Language Used for Text on the Display Screen
Selecting the Language Used for Text on the Display Screen

Close the front cover.

Hold down and turn on the
power switch.

Use or to select the
language.
Press to conrm.
ON

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
