Others Menu (Submenu)
P. 85, "Submenus"
This determines whether the spindle is rotated during cutting. When this is set to
“OFF,” scribing (cutting without rotation of the spindle) is performed.
Default setting: ON
Set this to “ON” in cases such as when you’re using the nose unit. Setting this to
“ON” enables automatic detection of the Z origin point as the position where the
tip of the nose unit or cutter touches the surface of the workpiece.
When the lock lever is positioned at
, set this to “OFF.” Leaving this set at “ON”
may cause an error and make operation impossible to continue.
Default setting: OFF
This is displayed when [AUTO Z CONTROL] is set to “ON.” This sets the cutout amount
when [AUTO Z CONTROL] is set to “ON.”
Default setting: 500 (5 mm)
This selects a resolution that matches the program used to create the engraving
data. When you’re performing output from the included Windows-based driver,
set this to “0.1mm.”
Default setting: 0.01 mm
The cutter stops moving when a command is received that species movement
outside the range of operation for the X and Y axes. Movement starts again when
a command to return from that location to the range of operation is received. You
can select either of the following as the response taken when this occurs.
[CONTINUE]:
When a command for return to the range of operation is received, operation
resumes immediately.
[PAUSE]:
When a command for return to the range of operation is received, operation is
paused and the Pause menu appears on the display screen. Use the operation
panel to select the operation to perform thereafter.
P. 49, “Pausing and Resuming Cutting”
Default setting:
CONTINUE
This selects whether the Z0, Z1, and Z2 locations are saved in memory on the
machine.
Default setting: ON
P. 78,"Executing Repeated Cutting," p.92,"Origin-setting Menu"
