Roland EGX-350 User Manual

3-5 Spindle Operation
Starting and Stopping Spindle Rotation
This manually starts and stops rotation of the spindle. You perform the operation using the handy panel.
 P. 35, “Spindle Run-in (Warm-up)”
Procedure

Close the front cover.

At the main screen, press and hold for one second
or longer.
A beep is heard, and the spindle starts to turn.

Press .
The spindle stops turning, a beep is heard.
This operation cannot be performed in the following situations.
 When the machine is performing some operation
 When the front cover is open (in which case the screen shown in the gure below is displayed)
 P. 103, “Responding to a Message”
Spindle rotation speed
Chapter 3 Basic Operation
47

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
