Roland EGX-350 User Manual

Emergency Stop Due to Opening or Closing the Front Cover
To ensure safety, opening the front cover during engraving or spindle rotation causes an emergency stop to occur, and the
message shown below appears on the display screen. Operation cannot be resumed by closing the front cover. To resume,
switch o the power, then start up again.
 P. 40, “Starting and Quitting”
Front cover
39
Chapter 3 Basic Operation
3-1 Types of Emergency Stops to Ensure Safety

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
