Roland EGX-350 User Manual

115
Chapter 8 Appendix
8-4 Main Unit Specication
Main Specications
EGX-350
Workpiece-table size Width x depth: 305 x 230 mm (12 x 9.1 in.)
X, Y, and Z operation strokes X, Y, and Z: 305 x 230 x 40 mm (12 x 9.1 x 1.6 in.)
X-, Y-, and Z-axis drive system Stepping motor, 3-axis simultaneous control
Operating speed X and Y axes: 0.1 to 60 mm/sec. (0.004 to 2.4 in./sec)
Z axis: 0.1 to 30 mm/sec. (0.004 to 1.2 in./sec)
Software resolution 0.01 mm/step or 0.025 mm/step (0.0004 in./step or 0.001 in./step)
Mechanical resolution X and Y axes: 0.0025 mm/step (0.0001 in./step)
Z axis: 0.00125 mm/step (0.00005 in./step)
Spindle motor brushless DC motor, maximum 50 W
Spindle speed 5,000 to 20,000 rpm
Tool chuck Cutter holder, collet method
Loadable workpiece thickness Maximum 40 mm (1.6 in.) (38 mm (1.5in.)when nose unit is used)
Interface USB (compliant with Universal Serial Bus Specication Revision 1.1)
Serial (RS-232C-compliant)
Internal memory capacity 2 MB
Control command set RML-1
Required power-supply amperage Voltage and frequency: AC 100 to 120 V/220 to 240 V ±10%, 50/60 Hz (overvolt-
age category II, IEC 60664-1)
Required power capacity: 1.3 A (100 to 120 V)/0.6 A (220 to 240 V)
Power consumption 122 W
Operating noise During operation: 60 dB(A) or less (when not cutting), during standby: 40
dB(A) or less
External dimensions Height x width x depth: 393 x 616 x 591 mm (15.5 x 24.3 x 23.3 in.)
Weight 34 kg (75 lb)
Installation Environment Operating environment: Temperature of 5 to 40°C (41 to 104 °F), 35 to 80%
relative humidity (no condensation)
Ambient pollution degree: 3 (as specied by IEC 60664-1)
Included items Power cord, depth regulator nose (nose unit), nose-unit retainer (retaining
screw, spring), spare mounting screw (for the cutter holder), character cutter
(diameter 3.175 mm), at cutter (diameter 3.175 mm), wrench, solid collet
(diameter 3.175 mm), solid collet (diameter 4.36 mm), hexagonal wrench,
hexagonal screwdriver, handy panel, adhesive sheet, vacuum adapter for chip
cleaning, Roland Software Package CD-ROM, Roland EngraveStudio CD-ROM,
Roland Software Package SOFTWARE GUIDE, Roland EngraveStudio Software
Guide, and User’s Manual (this document)
System Requirements for USB Connection
Computer 1) Model preinstalled with Windows XP/Vista/7 (32 bit edition/64 bit edition),
or upgraded computer originally preinstalled with Windows XP or later
2) Computers on which USB operation is assured by the manufacturer of
computers
USB cable Use a shielded cable up to three meters (10 ft.) in length.

Roland EGX-350 Specifications

General

Drive System	Stepper motor
Interface	USB
Engraving Area	350 x 300 mm
Engraving Area (mm)	300 x 210 mm
Software Resolution (mm)	0.01 mm/step
Spindle Speed	7, 000 rpm
Power Supply	AC 100 - 240 V, 50/60 Hz
Acoustic Noise	65 dB (A) or less (when not cutting)
Operating Temperature	5 - 40 °C
Operating Humidity	35 to 80% (no condensation)
External Dimensions (mm)	680 x 580 x 430
