Mechanical mounting
6.3 Installing/removing the rotor
SIMOTICS M-1FE2 built-in motors
102 Hardware Installation Manual, 04/2020, A5E50074509B AA
Table 6- 3 Maximum permissible oil pressure
Motor type
Maximum oil pressure P
max
/ MPa
1FE218☐-8☐
80
Table 6- 4 Oil that can be used for stress compensation
Viscosity
300 mm
2
/s at 20° C
e.g. type SKF LHMF 300
Note
For special designs with a rotor sleeve, please contact the relevant Siemens office.
Procedure when compensating for the mechanical stresses
NOTICE
Environmental harm due to leaking oil
The forcing of oil can cause oil to escape and result in environmental damage.
• Catch any escaping oil.
• Bind the escaping oil with a suitable oil binding agent.
• Dispose of the oil and oil binding agent in accordance with the legal regulations.
