Siemens SIMOTICS Series Hardware Installation Manual

Description
3.3 Technical features and system requirements for built-in motors
SIMOTICS M-1FE2 built-in motors
Hardware Installation Manual, 04/2020, A5E50074509B AA
31
3.3.2.2 Design and characteristics of the asynchronous versions 1FE2....-.A... and 1FE2...-.C...
Motor parts
Note
Special versions and construction variants may differ in the scope of delivery with respect to
certain te
chnical aspects.
1
Rotor in Cu or Al version
2
Stator without cooling jacket
3
Motor rating plate (type plate)
Figure 3-4 Parts of the 1FE2 built-in motor in the asynchronous version
Design of the stators for the asynchronous version
Stator without cooling jacket
1
Cables for power connection and tempera-
ture sensors
2
Winding overhang, cast
3
Stator core
Figure 3-5 Stator without cooling jacket, cast, cross section
