Description
3.3 Technical features and system requirements for built-in motors
SIMOTICS M-1FE2 built-in motors
48 Hardware Installation Manual, 04/2020, A5E50074509B AA
Note
Note for r4955
The number of OA applications is displ
ayed in r4950.
…8] contains the designation for OA application 1
…17] contains the designation for OA application 2, etc.
Only one OA application present.
In this case, p4956[0] is used to activate an OA application.
More than one OA application present.
The associated index for activating the OA application SERVCOUP depends on the
designation.
– If r4955[0…8] contains "SERVCOUP", then p4956[0] applies
– If r4955[9…17] contains "SERVCOUP", then p4956[1] applies, etc.
The parameter list shown here illustrates the conversion of the motor data for master-slave
operation.
In accordance with this parameter list, some reference values must be changed.
Note that some converter-specific parameters depend on the encoder or application.
If you have questions, please contact the Technical Support.
3.3.5 Version and operating modes of the motor in the asynchronous version
You can connect the windings of the asynchronous version in different variants.
Note
The 1FE2 motors do not require a series reactor.
