3.4 Rating plate data
SIMOTICS M-1FE2 built-in motors
54 Hardware Installation Manual, 04/2020, A5E50074509B AA
3.4.3 Rating plate details (type plate) of 1FE2 in asynchronous version, star-delta
connection
Figure 3-13 1FE2 synchronous version, star-delta connection
Position
Description / technical specifications
1 Type of motor
2
Motor type / designation / article number
3 Motor serial number
4
Degree of protection
5
Temperature class
6
Data matrix code
7
Certifications
8
Standard for all rotating electrical machines
9
Identification temperature monitoring
10
WEEE symbol
11 Information on water cooling, flow rate, maximum permissible coolant
temperature in °C, pressure of the cooling system in MPa
12
Manufacturer's address
13
Mass of stator and rotor in kg
14
Identification temperature sensor
15
Maximum values of the motor for delta connection
16
Technical specifications for S1 operation with delta connection
17
Maximum values of the motor for star connection
18 Technical specifications for S1 operation with star connection
19
Type of construction
