13 Appendix A: Technical Data
Communication
Inverter communication RS485, MPLC
PC communication 10 / 100 Mbps Ethernet / RS485
Max. Communication Range
RS485 1000m
Ethernet 100m
MPLC* 1000m
Communication Ports
RS485 7
Ethernet
5 × 10/100Mbps
ETH1/2/5 Ethernet port
ETH3/4 Fast dispatch port
Digital input 16
Digital output 4
Built-in MPLC 1
PT100/PT1000 2
Analog input 4 (AI1：0~10 Vdc，AI2~AI4：4~20 mA)
Power Supply
AC input 100V~277Vac, 50 / 60Hz
DC input 24Vdc, 1.25A
Power consumption
• Typ. 18W
• Max. 30W
Environment
Operating temperature - 30°C~+60°C
Storage temperature -40°C~+70°C
Operating humidity ≤ 95%, no condensation
Elevation ≤4000m
IP rating IP20
Mechanical Parameters
Dimensions (W x H x D) 440×44×224mm
Weight 3 kg
Installation Rack-mounting, wall mounting
99
