User Manual 7 Web Main Interface

7.6 Device Monitoring

Click Device Monitoring to view the corresponding information.

Device information such as real-time values, DC data, initial parameter, protection

parameter, general parameter, device instruction and device information can be viewed on

this interface.

7.6.1 RealTime Values

Realtime information such as power generation, device state, and active power can be

viewed on this page.

step 1 Click Device Monitoring > Realtime Values to view the corresponding information.

step 2 Click to select the device type.

- - End

7.6.2 DC Info

On this interface, voltage and current information of multiple inputs of MPPTs and strings can

be viewed.

Click Device Monitoring > DC Info to view the corresponding information.

7.6.3 Initial Parameter

Select the inverter and configure the initial parameter settings. Both individual and batch

settings are supported.

step 1 Click Device Monitoring > Initial Parameter to enter the corresponding page.

step 2 Optional: Click in the device list on the left, select the device type in the drop-down list,

and then select the device.

step 3 Select Country/Region and Grid Type.

step 4 Click Settings to set initial parameters for an individual device.

step 5 Optional: Set the initial parameters in batch.

i. Click Configure Synchronization.

ii. Select the desired devices in the pop-up dialog, and click Save to apply the changes.

- - End

Sungrow Logger4000 User Manual
