User Manual 7 Web Main Interface
When the Data Logger is connected to a device via the serial port, the settings of
Baud Rate , Parity Bit , and Stop Bit of the serial port should match those set for
the connected device, to ensure normal communication.
When PLC Access corresponding to COM1~COM7 is set to Enable , the baud
rates of COM1~COM7 will be automatically changed to 115200. And then MPLC node
parameters can be set. See 7.9.12.1 MPLC (Broadband PLC) .
- - End
7.9.11.2 Ethernet
On this interface, users can set the Ethernet parameters.
step 1 Click System > Port Parameter > Ethernet to enter the Ethernet page.
step 2 If Automatically Obtain IP Settings DHCP is set to Open, the IP address corresponding to the
port is invalid. Log in the device through the virtual IP address.
Port
Default IP
address
Subnet
mask
Gateway DNS1 DNS2
ETH1 12.12.12.12
255.255.25
5.0
12.12.12.1 1.2.4.8 8.8.8.8
ETH2 13.13.13.13
255.255.25
5.0
13.13.13.1 1.2.4.8 8.8.8.8
ETH5 14.14.14.14
255.255.25
5.0
14.14.14.1 1.2.4.8 8.8.8.8
step 3 If the parameter Automatically obtain IP settings (DHCP) is set to Close, fill in the information
such as the IP Address, Subnet Mask, and Default Gateway, and click to save the
operation.
- - End
7.9.11.3 AI
step 1 Click System > Port Parameter > AI to enter the AI page.
step 2 Select Input Type, set Lower Limit and Upper Limit, and click to save the operation.
AI Port Input Type Lower Limit Upper Limit
AI1 Voltage(V) 0 10
AI2 Current(mA) 4 20
69
To Next Page
