User Manual 8 Grid Dispatching Function
Parameters Description
Feed-in Stop**
• Enable: When feed-in power is detected, the Data Logger will
deliver a stop command to the inverter.
• Disable: When feed-in power is detected, the Data Logger will
not deliver stop instruction to the inverter.
Note: Use the enable switch with caution. In general, keep it in the
disabled state unless necessary.
Control Cycle
Time interval of delivering dispatching commands
Range: 5~60s
Instruction Type
kW: set active power value
%: set active power percentage
The parameters noted with * refer to the parameters that need to be set only when Control
Method is set to Closed-Loop Control.
The parameters noted with ** refer to the parameters that need to be set only when Control
Method is set to Closed-Loop Control, and a Smart Energy Meter or transformer is selected.
step 4
Add local power control manner.
Fill in the Time, and Fixed Value of Active Power or Percentage, and click Save.
- - End
Subsequent Operation
Delete local power control manner: select a local control manner that needs to be deleted,
and click Clear Data.
8.2.1.4 Analog Input
When using the analog signal at the AI port of the Data Logger as the dispatching input, set
Active Control Mode to Analog Input.
step 1 Click Power Control > Active Power to enter the Active Power page.
step 2 Set Active Control Mode to Analog Input.
77
