Specifications
This chapter contains specifications for the instrument. All specifications are guaranteed unless noted as "typical." Typical
specifications are provided for your convenience but are not guaranteed. Specifications that are marked with the symbol are
checked in Performance Verification.
All specifications apply to all models unless noted otherwise. To meet specifications, two conditions must first be met:
■
The instrument must have been operating continuously for twenty minutes within the specified operating temperature range.
■
You must perform the Signal Path Compensation (SPC) operation. If the operating temperature changes by more than
10 °C (18 °F), you must perform the SPC operation again.
Vertical system analog channels
Analog bandwidth Bandwidth with a TCA292D adapter on TekConnect channels or directly into ATI channel.
Ambient temperature 18ºC to 28ºC assumed for all guaranteed bandwidth specifications.
Enhanced bandwidth is guaranteed at the following full scale (FS) stepped gain settings:
TekConnect channels: 62.5 mV, 100 mV, 200 mV, 500 mV, 1 V, 2 V, and 5 V.
ATI channel: All settings from 100 mV through 300 mV.
DPO70000SX Series User 187
