Mechanical specifications
Weight
DPO70000SX models 19 kg (42 lbs) oscilloscope only
Dimensions
DPO70000SX models
157 mm (6.0 in) height
452 mm (17.8 in) width
553 mm (21.8 in) depth
DPO70000SX models,
Rackmount configuration
177 mm (7.0 in) height
440 mm (19.75 in) width
523 mm (20.6 in) depth (from rack mounting ear to back of instrument)
Cooling
Required clearances
Fan-forced air circulation with no air filter
Top 0 mm (0 in)
Bottom 6.35 mm (0.25 in) minimum or 0 mm (0 in) when
standing on feet, flip stands down
Left side 76 mm (3 in)
Right side 76 mm (3 in)
Rear 0 mm (0 in) on rear feet
Construction material Chassis parts are constructed of aluminum alloy, front panel is constructed of plastic laminate,
circuit boards are constructed of glass laminate
Environmental specifications
Temperature
Operating +5 °C to +45 °C (41 °F to +113 °F), with 11 °C per hour maximum gradient, noncondensing,
derated 1 °C per 300 meters (984.25 feet) above 1500 meters (4921.25 feet) altitude
Nonoperating -20 °C to +60 °C (-4 °F to +140 °F), with 20 °C/hour maximum gradient
Humidity
Operating 8% to 80% relative humidity at up to +32 °C (+90 °F)
5% to 45% relative humidity above +32 °C (+90 °F) up to +45 °C (+113 °F), noncondensing, and is
limited by a maximum wet-bulb temperature of +29.4 °C (+85 °F) (derates relative humidity to 32%
at +45 °C (+113 °F)
Nonoperating 5% to 95% relative humidity at up to +30 °C (+86 °F),
5% to 45% relative humidity above +30 °C (+86 °F), up to +60 °C (+140 °F), noncondensing, and
is limited by a maximum wet-bulb temperature of +29.4 °C (+85 °F) (derates relative humidity to
11% at +60 °C (+140 °F))
Specifications
DPO70000SX Series User 195
