±5 V absolute maximum input.
>1.2 V/FS settings: ±8.0 V. Limited by maximum Vterm current and the attenuator power.
ATI Channel: ± 0.75 V
pk
Aux channel: ±5.0 V
pk
Power supply requirements
The power supply requirements for your instrument are listed in the following table.
Source Voltage and Frequency Power Consumption
100 VAC to 240 VAC, 50/60 Hz
or 115 VRMS, 400 Hz.
980 W
WARNING.
To reduce the risk of fire and shock, ensure that the mains supply voltage fluctuations do not exceed 10% of the operating
voltage range.
Preventing instrument damage
Preventing ESD
CAUTION. A direct electrostatic discharge can damage the instrument input. To learn how to avoid this damage, read the
following information.
Electrostatic discharge (ESD) is a concern when handling any electronic equipment. The instrument is designed with robust ESD
protection, however it is still possible that large discharges of static electricity directly into the signal input may damage the
instrument. To avoid damage to the instrument, use the following techniques to prevent electrostatic discharge to the instrument.
1. Discharge the static voltage from your
body by wearing a grounded antistatic
wrist strap while connecting and
disconnecting cables and TekConnect
adapters. The instrument provides a front
panel connection for this purpose.
Install your instrument
DPO70000SX Series User 3
