MOWER DECK
7-45LX Lawn Tractor Service Manual
7
42” Mower Deck - Spindle
Replacement
Installation
11. Remove the 4 self-tapping screws securing the
spindle housing to the mower deck (Fig. 714).
1. Lift the mower deck and position the spindle assem-
bly to the mower deck opening (Fig. 716).
Fig 714 PICT-7718
Fig 716 PICT-7755
Note: Ensure the deck brake is positioned in the
groove of the pulley.
2. Install 4 self-tapping screws securing the spindle
housing to the mower deck. Torque each screw to
16.7 to 33.3 ft-lbs. (23 to 45 Nm) (Fig. 717).
12. Lift the mower deck and remove the mower deck
spindle (Fig. 715).
Fig 717 PICT-7718
Fig 715 PICT-7722
