CHASSIS
3-29LX Lawn Tractor Service Manual
3
Fig 114 PICT-7094
7. Lower the tractor to the ground.
8. Install the mower deck onto the tractor. Refer to “50”
Mower Deck Installation” on page 7-76.
2. Disconnect the fuel line from the fuel fi lter and drain
all the fuel from the fuel tank into an approved
container (Fig. 114).
Fig 113 PICT-7063
Fig 112 PICT-7977a
1. Raise the hood (Fig. 113).
5. Route the clutch plug through the slot in the frame.
6. Plug the clutch into the wire harness (Fig. 112).
Removal
Fuel Tank Replacement
