MOWER DECK
7-69LX Lawn Tractor Service Manual
7
11. Install the mower deck belt around the lower engine
pulley (Fig. 810).
Fig 810 PICT-9675
12. Tighten the self-tapping screw to secure the belt
retainer rod to the frame (Fig. 811).
Fig 811 PICT-9668
46” Mower Deck Removal
13. Raise the lift lever to the highest height-of-cut setting
(Fig. 812).
Fig 812 PICT-9680
1. Lower the lift lever to the lowest height-of-cut setting
(Fig. 813).
Fig 813 PICT-9701
