CHASSIS
3-32 LX Lawn Tractor Service Manual
3
Fig 124 PICT-7066
Fig 126 PICT-7063
1. Position the hood on the chassis (Fig. 124).
3. Lower the hood (Fig. 126).
Fig 125 PICT-7064
Fig 123 PICT-7066
2. Plug the headlights to the wire harness (Fig. 125).3. Remove the hood from the chassis (Fig. 123).
Installation
