CHASSIS
3-19LX Lawn Tractor Service Manual
3
Fig 074 PICT-7067
10. Install the hub cap (Fig. 074).
Fig 073 PICT-7092
9. Apply grease to the wheel bearing (Fig. 073).
11. Lower the machine.
Fig 075 PICT-7103
1. Remove the steering wheel cap (Fig. 075).
Steering Wheel Replacement
Removal
Fig 076 PICT-7104
2. Remove the bolt and washer securing the steering
wheel to the steering shaft (Fig. 076).
