Toyota 22R-E User Manual

U/S 0.25
Circle runout Limit
Main journal taper and out–of–round
Limit
Crank pin journal taper and out–of round
Limit
STD
Limit
Rod bend per 100 mm (3.94 in.)
Limit
Rod twist per 100 mm (3.94 in.)
Limit
Main bearing center wall thickness
STD
Main journal diameter
Main journal finished diameter
Crank pin diameter
Crank pin finished diameter
Connecting
rod
and bearing
(cont’d)
Connecting rod bearing center wall thickness
Pin to bushing oil clearance
Main journal oil clearance
STD
Limit
STD
Thrust washer thickness
Big end inner diameter
STD
Limit
STD
Thrust clearance
Crankshaft
STD
–ENGINE ENGINE MECHANICAL
EG1–79

Toyota 22R-E Specifications

General

Displacement	2.4 L (2366 cc)
Fuel System	Electronic Fuel Injection (EFI)
Compression Ratio	9.0:1
Torque	142 lb⋅ft (193 N⋅m) at 3, 400 rpm
Block Material	Cast Iron
Head Material	Aluminum
Engine Type	Inline-4
Bore x Stroke	92 mm x 89 mm (3.62 in x 3.50 in)
Valvetrain	SOHC, 2 valves per cylinder
Power Output	112 hp (84 kW) at 4, 600 rpm
