(2) Check that there is voltage between ECM terminals + B (+ B1)
and E1. (IG SW ON)
(1) There is no voltage between ECM terminals Vc and E2 (E21).
(IG SW ON)
Check wiring between ECM and
volume air flow meter.
Intake air temperature 20C
(68 F)
(1) Check volume air flow
meter.
Replace or repair
volume air flow meter.
Measuring plate fully closed
Measuring plate fully open
Replace or repair wiring.
Ignition switch
ON
Try another ECM.
Ignition
switch
ON
• Vc –E2 (E21)
Refer to No. 1.
STD Voltage
No voltage
Terminals
Condition
Trouble
Idling
BAD
BAD
No.
–ENGINE MFI SYSTEM
EG1–147

Toyota 22R-E Specifications

General

Displacement	2.4 L (2366 cc)
Fuel System	Electronic Fuel Injection (EFI)
Compression Ratio	9.0:1
Torque	142 lb⋅ft (193 N⋅m) at 3, 400 rpm
Block Material	Cast Iron
Head Material	Aluminum
Engine Type	Inline-4
Bore x Stroke	92 mm x 89 mm (3.62 in x 3.50 in)
Valvetrain	SOHC, 2 valves per cylinder
Power Output	112 hp (84 kW) at 4, 600 rpm
