Toyota 22R-E User Manual

Engine Coolant
Temp. Sender Gauge
Circuit Opening
Relay
Fuel Pressure
Control System
Brakes drag even
when released
PNP Switch or
Clutch Start SW
Oil Pressure
Switch
Accelerator
Pedal Link
Fuel Cut System
Coolant Leakage
EFI Main
Relay
Cylinder Block
Starter Relay
Fuel Leakage
EGR System
Fuel Quality
Oil Leakage
Spark Plug
Thermostat
Distributor
EG1–88
or 92
Generator
Drive Belt
AT or CL
section
Starter
EG1–210
EG1–206
CH
section
EG1–219
BE
section
EG1–207
EG1–215
CH
section
ST
section
BE
section
EG1–235
EG1–228
EG1–225
ST
section
EG1–55
ECM
IG–6
IG–7
–ENGINE ENGINE MECHANICAL
EG1–9

Toyota 22R-E Specifications

General

Displacement	2.4 L (2366 cc)
Fuel System	Electronic Fuel Injection (EFI)
Compression Ratio	9.0:1
Torque	142 lb⋅ft (193 N⋅m) at 3, 400 rpm
Block Material	Cast Iron
Head Material	Aluminum
Engine Type	Inline-4
Bore x Stroke	92 mm x 89 mm (3.62 in x 3.50 in)
Valvetrain	SOHC, 2 valves per cylinder
Power Output	112 hp (84 kW) at 4, 600 rpm
