(c) Install the water pump with the seven bolts.
Torque:
Bolt (A) 18 N–m (185 kgf–cm. 13 ft–lbf)
Bolt (B) 20 N–m (200 kgf–cm, 14 ft–lbf)
2. CONNECT NO.2 OIL COOLER HOSE
3. INSTALL THERMOSTAT
4. INSTALL TIMING BELT
(See page EG2–41)
–ENGINE COOLING SYSTEM
EG2–267

Toyota 22R-E Specifications

General

Displacement	2.4 L (2366 cc)
Fuel System	Electronic Fuel Injection (EFI)
Compression Ratio	9.0:1
Torque	142 lb⋅ft (193 N⋅m) at 3, 400 rpm
Block Material	Cast Iron
Head Material	Aluminum
Engine Type	Inline-4
Bore x Stroke	92 mm x 89 mm (3.62 in x 3.50 in)
Valvetrain	SOHC, 2 valves per cylinder
Power Output	112 hp (84 kW) at 4, 600 rpm
